Float And Board Type Level Indicator Installation

The pulleys in turn are connected to a pointer which moves on a graduated scale by the side of the tank.

Float and board type level indicator installation. This gauge is also applicable to cone roof float roof floating roof under grand tanks etc. The horizontal float movement is as such the. Flowtech offer float board type water tank level indicators gauge suitable for large non pressurized liquid storage tanks vessels. Open scale target reading type float board level indicator 131 simple reliable and easy to install float type indicator supplied with all installation accessories to enable quick erection.

The float accurately follows liquid level variations in vertical direction. Liquid level indicators float borad type liquid level indicators float board type target indicator with guded floats liquid level indicators are used for accurate liquid level gauging of fixed roof tanks stating oil water simple easy installation for tanks in service or tanks out service and to provide a maximum of trouble free service. Friction less specially designed pulleys. Top mounted version designed specifically for sump application is available.

The float board level indicators consists of a float connected to a pointer through a rope via a set of pulleys. Pioneers in the industry we offer level indicator float and board level indicator float chord level indicator water level indicator liquid level indicator and tank level indicators from india. This type of level indicator doesn t require power making it ideal for a variety of applications across industries. The specific gravity of the fluid should be more than 0 6 free flow this level gauge wonks on the principle of buoyancy.

An indicator glides up and down the gauge board corresponding to the level within th. Gauge board are mounted vertically on the outside of the tank. Float and board level indicator is attached to a multi stand wire rope which passes through 2 nos. The pointer glides over a calibrated gauge board positioned parallel to the tank.

Mounted inside of the tank is a set of guide wires attached with top guide wire tensioners and bottom anchors this lets the float travel parallel with the level indicator.
